846-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Number of Rows [custom] | Card Type | Termination | Contact Finish | Number of Positions | Gender | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Contact Material | Color | Number of Positions/Bay/Row | Mounting Type | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Dual | Copper Alloy | Green | 29 | Right Angle Through Hole | Cantilever | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Wire Wrap | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Wire Wrap | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Dual | Copper Alloy | Green | 29 | Through Hole | Cantilever | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Gold | 58 | Female | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Dual | Copper Alloy | Green | 29 | Board Edge Straddle Mount | Cantilever | 125 °C | -40 C | Card Extender |
