UF220 Series
Manufacturer: Mechatronics Fan Group
Beta
⌘K
IMPELLER 223X71MM 230VAC RING
| Part | Current Rating (Amps) | Material - Frame | Material - Blade | Fan Type | Termination | Bearing Type | Width [y] | RPM | Features | Size / Dimension [diameter] | Size / Dimension | Power (Watts) | Static Pressure | Static Pressure | Air Flow | Air Flow | Operating Temperature [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Rated | Approval Agency | Noise | Weight | Weight | Weight [custom] | Weight [custom] | Width |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mechatronics Fan Group | 390 mA | Aluminum | Polyamide (PA) Nylon | Motorized Impellers | 4 Wire Leads | Ball | 97.8 mm | 2650 RPM | Permanent Split Capacitor Motor Thermal Overload Protector (TOP) | 259 mm | Round | 117 W | 423.5 Pa | 1.7 in H2O | 434 CFM | 12.15 m³/min | -40 C | 50 °C | -40 °C | 50 °C | 230 VAC | CE cUL TUV UL | 65 dB | 4.1 lbs | 1.9 kg | |||
 Mechatronics Fan Group | 800 mA | Aluminum | Polyamide (PA) Nylon | Motorized Impellers | 4 Wire Leads | Ball | 2650 RPM | Permanent Split Capacitor Motor Speed Sensor (Tach) Thermal Overload Protector (TOP) | 223 mm | 117 W | 423.5 Pa | 1.7 in H2O | 530 CFM | 14.84 mł/min | -40 C | 50 °C | -40 °C | 50 °C | 115 VAC | CE cUL TUV UL | 70 dB(A) | 3.2 lbs | 1.5 kg | 71 mm | ||||
Mechatronics Fan Group | 800 mA | Aluminum | Polyamide (PA) Nylon | Motorized Impellers | 4 Wire Leads | Ball | 2650 RPM | Permanent Split Capacitor Motor Thermal Overload Protector (TOP) | 223 mm | 117 W | 423.5 Pa | 1.7 in H2O | 530 CFM | 14.84 mł/min | -40 C | 50 °C | -40 °C | 50 °C | 115 VAC | CE cUL TUV UL | 70 dB(A) | 3.2 lbs | 1.5 kg | 71 mm | ||||
 Mechatronics Fan Group | 800 mA | Aluminum | Polyamide (PA) Nylon | Motorized Impellers | 4 Wire Leads | Ball | 97.8 mm | 2650 RPM | Permanent Split Capacitor Motor Thermal Overload Protector (TOP) | 259 mm | Round | 117 W | 423.5 Pa | 1.7 in H2O | 434 CFM | 12.15 m³/min | -40 C | 50 °C | -40 °C | 50 °C | 115 VAC | CE cUL TUV UL | 65 dB | 4.1 lbs | 1.9 kg | |||
 Mechatronics Fan Group | 390 mA | Aluminum | Polyamide (PA) Nylon | Motorized Impellers | 4 Wire Leads | Ball | 2650 RPM | Permanent Split Capacitor Motor Thermal Overload Protector (TOP) | 223 mm | 117 W | 423.5 Pa | 1.7 in H2O | 530 CFM | 14.84 mł/min | -40 C | 50 °C | -40 °C | 50 °C | 230 VAC | CE cUL TUV UL | 70 dB(A) | 3.2 lbs | 1.5 kg | 71 mm |
