846-096 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 96POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Mounting Type | Color | Number of Positions/Bay/Row | Pitch | Pitch | Number of Rows [custom] | Contact Material | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Read Out | Card Thickness [Max] | Card Thickness [Min] | Termination | Number of Positions | Gender | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.156 " | 3.96 mm | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 96 | Female | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.116 " | 2.95 mm | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 96 | Female | Floating Bobbin Flush Mount | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.156 " | 3.96 mm | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 96 | Female | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.128 " | 3.25 mm | Gold | Board Edge Straddle Mount | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 96 | Female | Flush Mount Top Opening Unthreaded | Card Extender |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 96 | Female | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 96 | Female | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.128 " | 3.25 mm | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 96 | Female | Flush Mount Side Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | 96 | Female | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.128 " | 3.25 mm | Gold | Right Angle Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 96 | Female | Flush Mount Side Opening Unthreaded | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.128 " | 3.25 mm | Gold | Through Hole | Green | 48 | 3.18 mm | 0.125 in | 2 | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 96 | Female | Side Mount Opening Unthreaded |
