333-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 50 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Termination Rows [custom] | Material - Insulation | Color | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Number of Positions | Read Out | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Number of Positions/Bay/Row | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Termination | Contact Finish | Mounting Type | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Gold | Through Hole | 2 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Gold | Right Angle Through Hole | 2 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Gold | Through Hole | 2 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Gold | Right Angle Through Hole | 2 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Gold | Board Edge Straddle Mount | 2 | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Gold | Through Hole | 2 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Gold | Through Hole | 2 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Gold | Through Hole | 2 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Gold | Through Hole | 2 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Green | Cantilever | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | 50 | Dual | Female | -40 C | 105 ░C | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Gold | Through Hole | 2 |
