200241 Series

Mega-Fit Right-Angle Header, Single Row, 5.70mm Pitch, 6 Circuits, 0.760µm Gold (Au) Plating, UL 94V-0, Glow-Wire Capable, Black

Manufacturer: Molex

Catalog

Mega-Fit Right-Angle Header, Single Row, 5.70mm Pitch, 6 Circuits, 0.760µm Gold (Au) Plating, UL 94V-0, Glow-Wire Capable, Black

Part	Features	Current Rating (Amps)	Connector Type	Insulation Material	Contact Type	Insulation Color	Number of Rows	Contact Finish - Post	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Fastening Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Shrouding	Style	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Insulation Height	Insulation Height	Contact Shape	Voltage Rating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions	Termination	Contact Length - Post	Contact Length - Post	Contact Finish - Mating
Molex 2002411218	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	105 ░C	Through Hole Right Angle	Latch Holder	60 Áin	1.52 Ám	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.437 in	11.1 mm	Square	600 VAC	60 µin	1.52 µm	8	Solder
Molex 2002411115	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	105 ░C	Through Hole	Latch Holder	60 Áin	1.52 Ám	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.602 in	15.29 mm	Square	600 VAC	60 µin	1.52 µm		Solder	3.23 mm	0.127 in
Molex 2002411123	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	120 °C	Through Hole	Latch Holder	15 µin	0.38 µm	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.602 in	15.29 mm	Square	600 VAC	100 µin	2.54 µm		Solder	3.23 mm	0.127 in	Gold
Molex 2002411223	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	120 °C	Through Hole Right Angle	Latch Holder	15 µin	0.38 µm	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.437 in	11.1 mm	Square	600 VAC	100 µin	2.54 µm		Solder			Gold
Molex 2002411138	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	120 °C	Through Hole	Latch Holder	30 Áin	0.76 Ám	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.602 in	15.29 mm	Square	600 VAC	100 µin	2.54 µm	8	Solder	3.23 mm	0.127 in	Gold
Molex 2002411212	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	105 ░C	Through Hole Right Angle	Latch Holder	60 Áin	1.52 Ám	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.437 in	11.1 mm	Square	600 VAC	60 µin	1.52 µm	2	Solder
Molex 2002411224	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	120 °C	Through Hole Right Angle	Latch Holder	15 µin	0.38 µm	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.437 in	11.1 mm	Square	600 VAC			4	Solder			Gold
Molex 2002411117	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	105 ░C	Through Hole	Latch Holder	60 Áin	1.52 Ám	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.602 in	15.29 mm	Square	600 VAC	60 µin	1.52 µm	7	Solder	3.23 mm	0.127 in
Molex 2002411116	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	105 ░C	Through Hole	Latch Holder	60 Áin	1.52 Ám	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.602 in	15.29 mm	Square	600 VAC	60 µin	1.52 µm	6	Solder	3.23 mm	0.127 in
Molex 2002411118	Board Guide Glow Wire Compliant	Varies by Wire Gauge	Header	Liquid Crystal Polymer (LCP)	Male Pin	Black	1	Tin	All	-40 °C	105 ░C	Through Hole	Latch Holder	60 Áin	1.52 Ám	Copper	Shrouded - 4 Wall	Board to Cable/Wire	UL94 V-0	0.224 in	5.7 mm	0.602 in	15.29 mm	Square	600 VAC	60 µin	1.52 µm	8	Solder	3.23 mm	0.127 in
