GSGX-N Series
Manufacturer: Kycon, Inc.
Beta
⌘K
GANGJACK 3PORT RT< 8P8C BLK 50U
| Part | Housing Material | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | LED Color | Tab Direction | Number of Positions/Contacts | Features | Contact Finish | Mounting Type | Termination | Number of Rows | Contact Material | Connector Type | Shielding | Number of Ports | Orientation | Ratings | Contact Finish Thickness | Number of Ports [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | 50 µin | 1.27 µm | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | Unshielded | 3 | 90 ° | Cat5 | ||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | 50 µin | 1.27 µm | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | Shielded | 8 | 90 ° | Cat5 | ||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | 50 µin | 1.27 µm | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | Shielded | 2 | 90 ° | Cat5 | ||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | Unshielded | 10 | 90 ° | Cat5 | Flash | |||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | 50 µin | 1.27 µm | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | Unshielded | 2 | 90 ° | Cat5 | ||
 Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | EMI Finger Shielded | 4 | 90 ° | Cat5 | Flash | |||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | EMI Finger Shielded | 2 | 90 ° | Cat5 | Flash | |||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | 50 µin | 1.27 µm | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | Unshielded | 10 | 90 ° | Cat5 | ||
Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | 50 µin | 1.27 µm | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | Shielded | 90 ° | Cat5 | 6 | ||
 Kycon, Inc. | Polybutylene Terephthalate (PBT) Glass Filled | 85 °C | -40 C | Does Not Contain LED | Down | 8p8c (RJ45 Ethernet) | Board Lock | Gold | Through Hole | Solder | 1 | Phosphor Bronze | Jack | EMI Finger Shielded | 2 | 90 ° | Cat5 | Flash |
