AA04D Series

Catalog

AC/DC POWER SUPPLY DUAL-OUT -15V/15V -0.133A/0.133A 4W 7-PIN

Part	Line Regulation	Weight	Weight	Load Regulation	Voltage - Output 1	Current - Output (Max)	Package / Case	Applications	Approval Agency	Efficiency	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Features	Mounting Type	Voltage - Input [Min]	Voltage - Input [Max]	Power (Watts)	Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Standard Number	Current - Output (Max) [Max]
Delta Electronics AA04D1515A	0.5 %	0.057 lb	25.85 g	0.5 %	15 V	133 mA	7-DIP Module	ITE (Commercial)	CE UL	77 %	2	60 °C	-25 °C	Universal Input	Through Hole	85 VAC 120 VDC	264 VAC 370 VDC	4 W	Enclosed	1.06 in	1.44 in	17.1 mm	0.67 in	27 mm	36.5 mm	60950-1
Delta Electronics AA04D1212A	0.5 %	0.057 lb	25.85 g	0.5 %	12 V		7-DIP Module	ITE (Commercial)	CE UL	77 %	2	60 °C	-25 °C	Universal Input	Through Hole	85 VAC 120 VDC	264 VAC 370 VDC	4 W	Enclosed	1.06 in	1.44 in	17.1 mm	0.67 in	27 mm	36.5 mm	60950-1	166 mA
