395-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Material - Insulation | Termination Rows | Contact Type | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Color | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Contact Material | Gender | Number of Positions/Bay/Row | Card Type | Card Thickness [Max] | Card Thickness [Min] | Termination | Features | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 20 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Single | Black | Through Hole | 0.25 Ám | 10 Áin | 1 | Copper Alloy | Female | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 20 | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Single | Black | Right Angle Through Hole | 0.25 Ám | 10 Áin | 1 | Copper Alloy | Female | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 20 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Single | Black | Right Angle Through Hole | 0.25 Ám | 10 Áin | 1 | Copper Alloy | Female | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | 20 | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Dual | Black | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Female | 10 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | 20 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Dual | Black | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Copper Alloy | Female | 10 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Extender | 2 | 2 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | 20 | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Single | Black | Through Hole | 0.25 Ám | 10 Áin | 1 | Copper Alloy | Female | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | 20 | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Dual | Black | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Female | 10 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | 20 | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Dual | Black | Right Angle Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Female | 10 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Guides | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | 20 | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Dual | Black | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Copper Alloy | Female | 10 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Extender Card Guides | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | 20 | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | Gold | -40 C | 105 ░C | Dual | Black | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Female | 10 | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 2 | 2 |
