845-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 50POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Mounting Type | Card Type | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Read Out | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Contact Material | Termination | Number of Positions | Contact Type | Gender | Color | Features | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Through Hole | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 25 | Dual | 2 | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Solder | 50 | Cantilever | Female | Green | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Board Edge Straddle Mount | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 25 | Dual | 2 | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Solder | 50 | Cantilever | Female | Green | Card Extender | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 50 | Single | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Solder Eyelet(s) | 50 | Cantilever | Female | Green | 0.128 " | 3.25 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 50 | Single | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Solder | 50 | Cantilever | Female | Green | 0.128 " | 3.25 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 50 | Single | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Solder | 50 | Cantilever | Female | Green | 0.156 " | 3.96 mm | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 50 | Single | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Solder | 50 | Cantilever | Female | Green | 0.156 " | 3.96 mm | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Through Hole | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 25 | Dual | 2 | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Wire Wrap | 50 | Cantilever | Female | Green | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 50 | Single | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Wire Wrap | 50 | Cantilever | Female | Green | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Through Hole | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 25 | Dual | 2 | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Wire Wrap | 50 | Cantilever | Female | Green | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Through Hole | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 25 | Dual | 2 | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Copper Alloy | Solder | 50 | Cantilever | Female | Green |
