KSA0V2 Series

Catalog

SWITCH TACTILE SPST-NO 0.05A 32V

Part	Actuator Length, Right Angle [x]	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Actuator Type	Contact Rating @ Voltage	Illumination	Operating Force	Outline [y]	Outline [x]	Mounting Type	Switch Function	Ingress Protection	Actuator Orientation	Circuit
Littelfuse/Commercial Vehicle Products KSA0V211	3.23 mm	PC Pin	90 °C	-40 °C	Standard	0.05 A	Non-Illuminated	130 gf	8 mm	8 mm	Through Hole Right Angle	Off-Mom	IP60	Side Actuated	SPST-NO
Littelfuse/Commercial Vehicle Products KSA0V211 SS ETRIER LFTR
Littelfuse/Commercial Vehicle Products KSA0V211LFT	3.23 mm	PC Pin	90 °C	-40 °C	Standard	0.05 A	Non-Illuminated	130 gf	8 mm	8 mm	Through Hole Right Angle	Off-Mom	IP60	Side Actuated	SPST-NO
Littelfuse/Commercial Vehicle Products KSA0V211 LFTR	3.23 mm	PC Pin	90 °C	-40 °C	Standard	0.05 A	Non-Illuminated	130 gf	8 mm	8 mm	Through Hole Right Angle	Off-Mom	IP60	Side Actuated	SPST-NO
