9WV0848 Series
Manufacturer: Sanyo Denki America Inc.
Beta
⌘K
FAN AXIAL 80X38MM 48VDC WIRE
| Part | Current Rating (Amps) | Material - Blade | Lifetime @ Temp. | Material - Frame | Voltage Range [Max] | Voltage Range [Min] | Features | Approval Agency | Weight | Weight | RPM | Power (Watts) | Width [y] | Air Flow | Air Flow | Size / Dimension [z] | Size / Dimension [x] | Voltage - Rated | Static Pressure | Static Pressure | Operating Temperature [Min] | Operating Temperature [Max] | Noise | Termination | Bearing Type | Fan Type | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sanyo Denki America Inc. | 750 mA | Plastic | Varies Based on Temperature | Plastic | 52.8 VDC | 40.8 VDC | PWM Control Speed Sensor (Tach) | CSA TUV UL | 239.95 g | 0.529 lb | 9700 RPM | 36 W | 38 mm | 131 CFM | 3.67 mł/min | 80 mm | 80 mm | 48 VDC | 1.77 in H2O | 440.9 Pa | -20 ░C | 70 °C | 63 dB | 4 Wire Leads | Ball | Tubeaxial | IP68 - Dust Tight Waterproof |
