807-006 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 6POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Rows | Color | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Gender | Termination | Card Type | Contact Material | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Read Out | Contact Type | Flange Feature | Contact Finish | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Through Hole | 0.25 Ám | 10 Áin | Female | Solder | Non Specified - Single Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Semi Bellows | Flush Mount M3 Threaded Insert Top Opening | Gold | 3.96 mm | 0.156 in | 125 °C | -40 C | 6 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Through Hole | 0.25 Ám | 10 Áin | Female | Solder | Non Specified - Single Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 3.96 mm | 0.156 in | 125 °C | -40 C | 6 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Through Hole | Female | Solder | Non Specified - Single Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Semi Bellows | Tin | 3.96 mm | 0.156 in | 125 °C | -40 C | 6 | ||||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Through Hole | 0.25 Ám | 10 Áin | Female | Wire Wrap | Non Specified - Dual Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Semi Bellows | Flush Mount Top Opening Unthreaded | Gold | 3.96 mm | 0.156 in | 125 °C | -40 C | 12 | 0.156 " | 3.96 mm | 2 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Through Hole | 0.25 Ám | 10 Áin | Female | Wire Wrap | Non Specified - Dual Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Semi Bellows | Gold | 3.96 mm | 0.156 in | 125 °C | -40 C | 12 | 2 | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Through Hole | 0.25 Ám | 10 Áin | Female | Solder | Non Specified - Single Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Semi Bellows | Gold | 3.96 mm | 0.156 in | 125 °C | -40 C | 6 | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Through Hole | Female | Solder | Non Specified - Dual Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Semi Bellows | Flush Mount Top Opening Unthreaded | Tin | 3.96 mm | 0.156 in | 125 °C | -40 C | 12 | 0.128 " | 3.25 mm | 2 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Through Hole | Female | Solder | Non Specified - Dual Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Semi Bellows | Tin | 3.96 mm | 0.156 in | 125 °C | -40 C | 12 | 2 | ||||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Through Hole | Female | Wire Wrap | Non Specified - Dual Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Tin | 3.96 mm | 0.156 in | 125 °C | -40 C | 12 | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Through Hole | Female | Solder | Non Specified - Single Edge | Copper Alloy | 6 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Tin | 3.96 mm | 0.156 in | 125 °C | -40 C | 6 |
