5309 Series

Catalog

CABLE GLAND 26-39MM M63 POLYAMID

Part	Thread Length	Thread Length	Panel Hole Size	Panel Hole Size	Outside Cable Diameter (Min) [Min]	Outside Cable Diameter (Min) [Min]	Type	Color	Outside Cable Diameter (Max) [Max] [diameter]	Outside Cable Diameter (Max) [Max] [diameter]	Material	Ingress Protection	Operating Temperature [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Includes	Thread Size	Outside Cable Diameter (Min)	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Min) [Min] [diameter]	Panel Hole Size
TE Connectivity Raychem Cable Protection 5309 763	0.472 in	12 mm	63 mm	2.48 in	1.024 in	26 mm	Cable Gland	Black	39 mm	1.535 in	Polyamide (PA) Nylon	IP68 - Dust Tight Waterproof	-25 °C 100 °C
Altech Corporation 5309 763	0.472 in	12 mm	63 mm	2.48 in	1.024 in	26 mm	Cable Gland	Black	39 mm	1.535 in	Polyamide (PA) Nylon	IP68 - Dust Tight Waterproof	-25 °C 100 °C
Altech Corporation 5309 116/SET	0.394 in	10 mm	22.5 mm	0.886 in	0.197 in	5 mm	Cable Gland	Light Gray	12 mm	0.472 in		IP68 - Dust Tight Waterproof		100 °C	-40 °C	Locknut	PG16
Altech Corporation 5309 725/SET	0.394 in	10 mm	25 mm	0.984 in			Cable Gland	Black	16 mm	0.63 "	Polyamide (PA) Nylon	IP68 - Dust Tight Waterproof		100 °C	-40 °C	Locknut	M25x1.5	7 mm	0.276 in
TE Connectivity Raychem Cable Protection 5309 715/SET	0.394 in	10 mm	16 mm	0.63 in			Cable Gland	Black	6 mm	0.236 in		IP68 - Dust Tight Waterproof	-25 °C 100 °C			Locknut	M16x1.5		0.059 in	1.5 mm
Altech Corporation 5309 715/SET	0.394 in	10 mm	16 mm	0.63 in			Cable Gland	Black	6 mm	0.236 in		IP68 - Dust Tight Waterproof	-25 °C 100 °C			Locknut	M16x1.5		0.059 in	1.5 mm
Altech Corporation 5309 615	0.394 in	10 mm	16 mm	0.63 in			Cable Gland	Light Gray	6 mm	0.236 in		IP68 - Dust Tight Waterproof	-25 °C 100 °C				M16x1.5		0.059 in	1.5 mm
Altech Corporation 5309 624	0.394 in	10 mm	25 mm	0.984 in	0.197 in	5 mm	Cable Gland	Gray	12 mm	0.472 in	Polyamide (PA) Nylon	IP68 - Dust Tight Waterproof	-25 °C 100 °C				M25x1.5
TE Connectivity Raychem Cable Protection 5309 229/SET	0.433 in	11 mm	1.457 in				Cable Gland	Black	21 mm	0.827 in		IP68 - Dust Tight Waterproof		100 °C	-40 °C	Locknut	PG29		0.433 in	11 mm	37 mm
Altech Corporation 5309 229/SET	0.433 in	11 mm	1.457 in				Cable Gland	Black	21 mm	0.827 in		IP68 - Dust Tight Waterproof		100 °C	-40 °C	Locknut	PG29		0.433 in	11 mm	37 mm
