306-026 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 26 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows | Gender | Termination | Mounting Type | Flange Feature | Contact Material | Number of Positions/Bay/Row | Read Out | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Color | Pitch | Pitch | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder | Panel Mount Through Hole | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Tin | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder Eyelet(s) | Panel Mount | Flush Mount Side Opening Unthreaded | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Tin | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder | Panel Mount Through Hole | Floating Bobbin Flush Mount | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Tin | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder Eyelet(s) | Panel Mount | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder | Panel Mount Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder Eyelet(s) | Free Hanging (In-Line) | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Tin | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder | Panel Mount Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder Eyelet(s) | Panel Mount | Flush Mount Top Opening Unthreaded | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Solder | Panel Mount Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 26 | Dual | Non Specified - Dual Edge | -40 C | 105 ░C | 2 | Green | 3.96 mm | 0.156 in | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Tin |
