C3BBS-1 Series

Catalog

IDC CABLE - CSR14S/AE14M/CSR14S

Part	Number of Positions	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Pitch - Cable	Pitch - Cable	Cable Termination	Connector Type	Number of Rows [custom]	Features	Pitch - Connector	Pitch - Connector	Shielding	Color	Length [x]	Length [x]	Length	Length	Length
CW Industries C3BBS-1418M	14	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded	Multiple Ribbon	457.2 mm	1.5 ft
CW Industries C3BBS-1018G	10	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded		457.2 mm	1.5 ft
CW Industries C3BBS-1036M	10	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded	Multiple Ribbon			91.44 cm	3 ft
CW Industries C3BBS-1606M	16	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded	Multiple Ribbon			152.4 mm	0.5 '	6 "
CW Industries C3BBS-1436G	14	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded				91.44 cm	3 ft
CW Industries C3BBS-1018M	10	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded	Multiple Ribbon	457.2 mm	1.5 ft
CW Industries C3BBS-1006M	10	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded	Multiple Ribbon			152.4 mm	0.5 '	6 "
CW Industries C3BBS-1036G	10	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded				91.44 cm	3 ft
CW Industries C3BBS-1636M	16	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded	Multiple Ribbon			91.44 cm	3 ft
CW Industries C3BBS-1406G	14	Tin	2.54 µm	100 µin	0.05 in	1.27 mm	IDC	Socket to Socket	2	Strain Relief	0.1 in	2.54 mm	Unshielded				152.4 mm	0.5 '	6 "
