TA Series
Manufacturer: Amphenol Anytek
Beta
⌘K
TERM BLK 3POS SIDE ENT 7.5MM PCB
| Part | Clamp Material - Plating | Positions Per Level | Number of Levels | Mating Orientation | Mounting Type | Color | Screw Thread | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Torque - Screw | Torque - Screw | Screw Material - Plating | Wire Gauge [Min] | Wire Gauge [Max] | Features | Pitch [x] | Pitch [x] | Wire Termination | Current | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Anytek | Stainless Steel | 3 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Steel Zinc Plated | 14 AWG | 22 AWG | Interlocking (Side) | 0.295 in | 7.5 mm | Screw - Leaf Spring Wire Guard | 16 A | |
 Amphenol Anytek | Stainless Steel | 2 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Steel Zinc Plated | 14 AWG | 22 AWG | Interlocking (Side) | 0.2 in | 5.08 mm | Screw - Leaf Spring Wire Guard | 15 A | 300 V |
Amphenol Anytek | Stainless Steel | 10 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Steel Zinc Plated | 14 AWG | 22 AWG | Interlocking (Side) | 0.2 in | 5.08 mm | Screw - Leaf Spring Wire Guard | 15 A | 300 V |
Amphenol Anytek | Stainless Steel | 13 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Steel Zinc Plated | 14 AWG | 22 AWG | Interlocking (Side) | 0.2 in | 5.08 mm | Screw - Leaf Spring Wire Guard | 15 A | 300 V |
Amphenol Anytek | Stainless Steel | 7 | 1 | Horizontal with Board | Through Hole | Green | M3 | -40 °C | 115 °C | Thermoplastic | 0.3 Nm | 2.6 Lb-In | Steel Zinc Plated | 14 AWG | 26 AWG | Interlocking (Side) | 0.197 in | 5 mm | Screw - Leaf Spring Wire Guard | 16 A | |
Amphenol Anytek | Stainless Steel | 17 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.3 Nm | 2.6 Lb-In | Steel Zinc Plated | 14 AWG | 26 AWG | Interlocking (Side) | 0.197 in | 5 mm | Screw - Leaf Spring Wire Guard | 16 A | |
Amphenol Anytek | Stainless Steel | 8 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Steel Zinc Plated | 14 AWG | 22 AWG | Interlocking (Side) | 0.295 in | 7.5 mm | Screw - Leaf Spring Wire Guard | 16 A | |
 Amphenol Anytek | Stainless Steel | 2 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.3 Nm | 2.6 Lb-In | Steel Zinc Plated | 14 AWG | 26 AWG | Interlocking (Side) | 0.197 in | 5 mm | Screw - Leaf Spring Wire Guard | 16 A | |
Amphenol Anytek | Stainless Steel | 23 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.3 Nm | 2.6 Lb-In | Steel Zinc Plated | 14 AWG | 26 AWG | Interlocking (Side) | 0.197 in | 5 mm | Screw - Leaf Spring Wire Guard | 16 A | |
Amphenol Anytek | Stainless Steel | 5 | 1 | Horizontal with Board | Through Hole | Blue | M3 | -40 °C | 115 °C | Thermoplastic | 0.4 Nm | 3.5 Lb-In | Steel Zinc Plated | 14 AWG | 22 AWG | Interlocking (Side) | 0.295 in | 7.5 mm | Screw - Leaf Spring Wire Guard | 16 A |
