37200630001 Series

FUSE 250V IEC TL LBC TR5 LL AMMO .063A

Catalog

FUSE 250V IEC TL LBC TR5 LL AMMO .063A

Part	Fuse Type	DC Cold Resistance	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Melting I²t	Response Time	Size / Dimension [diameter]	Size / Dimension [z]	Size / Dimension [diameter]	Size / Dimension [z]	Mounting Type	Approval Agency	Breaking Capacity @ Rated Voltage	Voltage Rating - AC	Current Rating (Amps)
Littelfuse/Commercial Vehicle Products 37200630001	Board Mount	3.8 Ohms	85 °C	-40 °C	Can Radial Vertical	0.0278	Slow Blow	0.335 "	8 mm	8.5 mm	0.315 "	Through Hole	CCC cURus SEMKO VDE	35 A	250 V	63 mA

FUSE 250V IEC TL LBC TR5 LL AMMO .063A

• Lead-free

• Reduced PCB space requirements

• Direct solderable or plug-in versions

• Internationally approved

• Low internal resistance

• Shocksafe casing

• Halogen free
