9WP0648 Series
Manufacturer: Sanyo Denki America Inc.
Beta
⌘K
FAN AXIAL 60X25MM 48VDC WIRE
| Part | Voltage Range [Max] | Voltage Range [Min] | Current Rating (Amps) | Material - Blade | Material - Frame | Features | RPM | Operating Temperature [Min] | Operating Temperature [Max] | Noise | Power (Watts) | Width [y] | Ingress Protection | Weight | Weight | Termination | Bearing Type | Voltage - Rated | Fan Type | Size / Dimension [z] | Size / Dimension [x] | Approval Agency | Air Flow | Air Flow |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sanyo Denki America Inc. | 53 VDC | 40 V | 40 mA | Plastic | Plastic | Locked Rotor Sensor | 3800 RPM | -20 ░C | 70 °C | 28 dB | 1.92 W | 25 mm | IP68 - Dust Tight Waterproof | 110.22 g | 0.243 lb | 3 Wire Leads | Ball | 48 VDC | Tubeaxial | 60 mm | 60 mm | CSA TUV UL | 18.7 CFM | 0.524 mł/min |
