wt Series

Catalog

TOGGLE SWITCH, ON-ON, SPDT, NON ILLUMINATED, 10 A, PANEL MOUNT

Part	Mounting Type	Termination Style	Ingress Protection Description	Ingress Protection IP Rating	Circuit	Features	Illumination	Switch Function	Voltage Rating - AC	Current Rating	Operating Temperature (Max)	Operating Temperature (Min)	Panel Cutout Diameter	Panel Cutout Shape	Voltage Rating - DC	Actuator Length	Actuator Type	Bushing Thread Diameter	Bushing Thread	Bushing Thread Pitch
NKK Switches WT12S	Panel Mount	Solder Lug	Dust Tight Waterproof	IP67	SPDT	Epoxy Sealed Terminals	Non-Illuminated	On-On	125 V	10 A	70 °C	-30 °C	12.5 mm	Circular	30 V	17.5 mm	Standard Round	12 mm	M12 x 1	1 mm
NKK Switches WT25L	Panel Mount	Wire Leads	Dust Tight Waterproof	IP67	DPDT	Epoxy Sealed Terminals	Non-Illuminated	On-Mom	125 V	10 A	70 °C	-30 °C	12.5 mm	Circular	30 V	17.5 mm	Standard Round	12 mm	M12 x 1	1 mm
NKK Switches WT13L	Panel Mount	Wire Leads	Dust Tight Waterproof	IP67	SPDT	Epoxy Sealed Terminals	Non-Illuminated	On-Off-On	125 V	10 A	70 °C	-30 °C	12.5 mm	Circular	30 V	17.5 mm	Standard Round	12 mm	M12 x 1	1 mm
