284516 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN WIRE TO BOARD HDR 3 POS 3.5MM SOLDER ST THRU-HOLE
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Header Orientation | Contact Material | Positions Per Level | Type | Features | Termination Style | Insulation Height | Insulation Height | Material Flammability Rating | Current - UL | Color | Contact Tail Length | Contact Tail Length | Contact Mating Finish | Voltage - UL | Pitch [x] | Pitch [x] | Number of Levels | Mounting Type | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 3 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | |
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 11 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | 11 |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 5 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 2 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | 2 |
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 9 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | 9 |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 8 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | 8 |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 4 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | 4 |
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 12 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | 12 |
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | Phosphor Bronze | 21 | Header Male Pins Shrouded (4 Side) | Mating Flange | Solder | 0.362 in | 9.2 mm | UL94 V-0 | 11 A | Green | 3.4 mm | 0.134 in | Tin | 300 V | 3.5 mm | 0.138 in | 1 | Through Hole | 21 |
