9S0924 Series

Catalog

AXIAL FAN, SILENT, MEDIUM SPEED, 92 SERIES, 24 VDC, 92 MM, 25 MM, 0.63 CU.FT/MIN, 1.07 M3/MIN ROHS COMPLIANT: YES

Part	Lifetime @ Temp.	Air Flow	Air Flow	Voltage Range [Min]	Voltage Range [Max]	Current Rating (Amps)	Material - Frame	Material - Blade	Approval Agency	RPM	Bearing Type	Termination	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Weight [custom]	Weight [custom]	Voltage - Rated	Features	Fan Type	Width [y]	Size / Dimension [y]	Size / Dimension [x]	Static Pressure	Static Pressure	Noise
Sanyo Denki America Inc. 9S0924M4011	40000 Hrs	1.06 mł/min	37.8 CFM	14 VDC	26.4 VDC	70 mA	Plastic	Plastic	CSA TUV UL	2250 RPM	Ball	3 Wire Leads	70 °C	-10 °C	1.68 W	100.7 g	0.222 lb	24 VDC	Locked Rotor Protection Speed Sensor (Tach)	Tubeaxial	25 mm	92 mm	92 mm	21.7 Pa	0.087 in H2O	22 dB(A)
Sanyo Denki America Inc. 9S0924F4021	40000 Hrs	1.25 mł/min	44.5 CFM	14 VDC	26.4 VDC	0.09 A	Plastic	Plastic	CSA TUV UL	2650 RPM	Ball	2 Wire Leads	70 °C	-10 °C	2.16 W	100.7 g	0.222 lb	24 VDC		Tubeaxial	25 mm	92 mm	92 mm	29.9 Pa	0.12 in H2O	27 dB(A)
Sanyo Denki America Inc. 9S0924F4D01	40000 Hrs	1.25 mł/min	44.5 CFM	14 VDC	26.4 VDC	0.09 A	Plastic	Plastic	CSA TUV UL	2650 RPM	Ball	3 Wire Leads	70 °C	-10 °C	2.16 W	100.7 g	0.222 lb	24 VDC	Locked Rotor Sensor	Tubeaxial	25 mm	92 mm	92 mm	29.9 Pa	0.12 in H2O	27 dB(A)
Sanyo Denki America Inc. 9S0924L401	40000 Hrs	0.82 m³/min	29.3 CFM	14 VDC	26.4 VDC	40 mA	Plastic	Plastic	CSA TUV UL	1750 RPM	Ball	3 Wire Leads	70 °C	-10 °C	960 mW	100.7 g	0.222 lb	24 VDC	Locked Rotor Protection Speed Sensor (Tach)	Tubeaxial	25 mm	92 mm	92 mm	13.2 Pa	0.053 in H2O	17 dB
Sanyo Denki America Inc. 9S0924L4011	40000 Hrs	0.82 m³/min	29.3 CFM	14 VDC	26.4 VDC	40 mA	Plastic	Plastic	CSA TUV UL	1750 RPM	Ball	3 Wire Leads	70 °C	-10 °C	960 mW	100.7 g	0.222 lb	24 VDC	Locked Rotor Protection Speed Sensor (Tach)	Tubeaxial	25 mm	92 mm	92 mm	13.2 Pa	0.053 in H2O	17 dB
Sanyo Denki America Inc. 9S0924M402	40000 Hrs	1.06 mł/min	37.8 CFM	14 VDC	26.4 VDC	70 mA	Plastic	Plastic	CSA TUV UL	2250 RPM	Ball	2 Wire Leads	70 °C	-10 °C	1.68 W	100.7 g	0.222 lb	24 VDC		Tubeaxial	25 mm	92 mm	92 mm	21.7 Pa	0.087 in H2O	22 dB(A)
