Catalog
Circular Push Pull Connectors STRAIGHT PLUG MALE W. CABLE COLLET
Circular Push Pull Connectors STRAIGHT PLUG MALE W. CABLE COLLET
Circular Push Pull Connectors STRAIGHT PLUG MALE W. CABLE COLLET
| Part | Connector Type | Shell Size - Insert | Insert Material | Number of Positions | Shell Finish | Current Rating (Amps) | Cable Opening [Min] | Cable Opening [Min] | Cable Opening [Max] | Cable Opening [Max] | Features | Primary Material | Mounting Type | Shell Material | Ingress Protection | Material Flammability Rating | Orientation [custom] | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Shielding | Backshell Material, Plating | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Finish - Mating | Color | Fastening Type | Termination | Shell Size - Insert [custom] | Shell Size - Insert [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Plug Male Pins | 308 | Polyetheretherketone (PEEK) | 8 | Chrome | 5 A | 0.24 " | 6.1 mm | 0.256 in | 6.5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | ||||
Plug Male Pins | 314 | Polyetheretherketone (PEEK) | 14 | Chrome | 2 A | 0.24 " | 6.1 mm | 0.256 in | 6.5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | ||||
Plug Male Pins | Polyetheretherketone (PEEK) | 16 | Chrome | 1.5 A | 0.24 " | 6.1 mm | 0.256 in | 6.5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | Crimp | 316 | |||
Plug Male Pins | 303 | Polyetheretherketone (PEEK) | Chrome | 12 Amps | 0.161 in | 4.1 mm | 0.177 " | 4.5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | |||||
Plug Male Pins | 308 | Polyetheretherketone (PEEK) | 8 | Chrome | 5 A | 0.201 in | 5.1 mm | 0.217 in | 5.5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | ||||
Plug Male Pins | Polyetheretherketone (PEEK) | 7 | Chrome | 7 A | 0.22 in | 5.6 mm | 0.236 in | 6 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | 307 | ||||
Plug Male Pins | 302 | Polyetheretherketone (PEEK) | 2 | Chrome | 15 A | 0.319 in | 8.1 mm | 0.335 in | 8.5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | ||||
Plug Male Pins | Polyetheretherketone (PEEK) | 7 | Chrome | 7 A | 0.181 " | 4.6 mm | 0.197 in | 5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | 307 | ||||
Plug Male Pins | 302 | Polyetheretherketone (PEEK) | 2 | Chrome | 15 A | 0.22 in | 5.6 mm | 0.236 in | 6 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | ||||
Plug Male Pins | 308 | Polyetheretherketone (PEEK) | 8 | Chrome | 5 A | 0.24 " | 6.1 mm | 0.256 in | 6.5 mm | Backshell | Metal | Free Hanging (In-Line) Right Angle | Brass | IP66 IP68 | UL94 V-0 | G | 39.4 µin | 1 µm | Shielded | Brass Chrome | 200 °C | -55 C | Brass | Gold | Silver | Push-Pull | Crimp |
