CES48120 Series

Catalog

DC DC CONVERTER 12V 84W

Part	Voltage - Output 1	Type	Voltage - Input (Max) [Max]	Package / Case	Voltage - Input (Min) [Min]	Power (Watts)	Number of Outputs	Mounting Type	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Isolation	Applications	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Efficiency	Features
Cosel USA, Inc. CES48120-7P-R	12 V	Isolated Module	76 V	8-DIP Module	36 V	84 W	1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	7 A	-40 °C	85 °C
Cosel USA, Inc. CES48120-6-SV	12 V	Isolated Module	76 V	8-SMD Module	36 V	72 W	1	Surface Mount	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	6 A	-40 °C	85 °C	91 %
Cosel USA, Inc. CES48120-6-N	12 V	Isolated Module	76 V	8-DIP Module	36 V	72 W	1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	6 A	-40 °C	85 °C	91 %
Cosel USA, Inc. CES48120-7P-B	12 V	Isolated Module	76 V	8-DIP Module	36 V	84 W	1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	7 A	-40 °C	85 °C
Cosel USA, Inc. CES48120-6-S	12 V	Isolated Module	76 V	8-SMD Module	36 V	72 W	1	Surface Mount	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	6 A	-40 °C	85 °C	91 %
Cosel USA, Inc. CES48120-7P-BT	12 V	Isolated Module	76 V	8-DIP Module	36 V	84 W	1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	7 A	-40 °C	85 °C
Cosel USA, Inc. CES48120-7P-N	12 V	Isolated Module	76 V	8-DIP Module	36 V	84 W	1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	7 A	-40 °C	85 °C
Cosel USA, Inc. CES48120-6-V	12 V	Isolated Module	76 V	8-DIP Module	36 V	72 W	1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	6 A	-40 °C	85 °C	91 %
Cosel USA, Inc. CES48120-6-NS	12 V	Isolated Module	76 V	8-DIP Module	36 V	72 W	1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	6 A	-40 °C	85 °C	91 %
Cosel USA, Inc. CES48120-6	12 V	Isolated Module	76 V	8-DIP Module	36 V		1	Through Hole	0.33 in	57.9 mm	0.9 in	8.5 mm	22.8 mm	2.28 "	1.5 kV	ITE (Commercial)	6 A	-40 °C	85 °C	91 %	OCP OTP OVP Remote On/Off
