392-050 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 50POS 0.100
...
| Part | Pitch [x] | Pitch [x] | Read Out | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Termination Rows | Color | Gender | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Card Type | Contact Finish | Number of Positions | Material - Insulation | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Flange Feature | Number of Rows | Contact Type | Number of Positions/Bay/Row [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2.54 mm | 0.1 in | Single | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Single Edge | Gold | 50 | Polyester Thermoplastic | Through Hole Right Angle | -40 °C | 105 ░C | Solder Wire Wrap | Flush Mount M3 Threaded Insert Top Opening | 1 | Cantilever | 50 | |||
 EDAC Inc. | 2.54 mm | 0.1 in | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Dual Edge | Gold | 50 | Polyester Thermoplastic | Through Hole | -40 °C | 105 ░C | Wire Wrap | Flush Mount Top Opening Unthreaded | 2 | Cantilever | 25 | 3.25 mm | 0.128 " | |
 EDAC Inc. | 2.54 mm | 0.1 in | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Dual Edge | Gold | 50 | Polyester Thermoplastic | Through Hole | -40 °C | 105 ░C | Wire Wrap | 2 | Cantilever | 25 | ||||
 EDAC Inc. | 2.54 mm | 0.1 in | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Dual Edge | Gold | 50 | Polyester Thermoplastic | Through Hole Right Angle | -40 °C | 105 ░C | Solder Wire Wrap | 2 | Cantilever | 25 | ||||
 EDAC Inc. | 2.54 mm | 0.1 in | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Dual Edge | Gold | 50 | Polyester Thermoplastic | Board Edge Straddle Mount | -40 °C | 105 ░C | Solder | Flush Mount Top Opening Unthreaded | 2 | Cantilever | 25 | 3.25 mm | 0.128 " | Card Extender |
 EDAC Inc. | 2.54 mm | 0.1 in | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Dual Edge | Gold | 50 | Polyester Thermoplastic | Board Edge Straddle Mount | -40 °C | 105 ░C | Solder | 2 | Cantilever | 25 | Card Extender | |||
 EDAC Inc. | 2.54 mm | 0.1 in | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Dual Edge | Gold | 50 | Polyester Thermoplastic | Through Hole Right Angle | -40 °C | 105 ░C | Solder Wire Wrap | Flush Mount Side Opening Unthreaded | 2 | Cantilever | 25 | 3.25 mm | 0.128 " | |
 EDAC Inc. | 2.54 mm | 0.1 in | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Dual Edge | Gold | 50 | Polyester Thermoplastic | Through Hole | -40 °C | 105 ░C | Wire Wrap | Flush Mount M3 Threaded Insert Top Opening | 2 | Cantilever | 25 | |||
 EDAC Inc. | 2.54 mm | 0.1 in | Single | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Single Edge | Gold | 50 | Polyester Thermoplastic | Through Hole | -40 °C | 105 ░C | Solder | Flush Mount Side Opening Unthreaded | 1 | Cantilever | 50 | 3.25 mm | 0.128 " | |
 EDAC Inc. | 2.54 mm | 0.1 in | Single | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Black | Female | 10 Áin | 0.25 Ám | Copper Alloy | Non Specified - Single Edge | Gold | 50 | Polyester Thermoplastic | Through Hole | -40 °C | 105 ░C | Wire Wrap | Floating Bobbin Flush Mount | 1 | Cantilever | 50 | 2.95 mm | 0.116 in |
