GP2500S20 Series

Manufacturer: Bergquist

Catalog

THERMAL INTERFACE PRODUCTS GAP PAD, S-CLASS, 8"X16" SHEET, 0.040" THICKNESS, GAP PAD TGP2400/2500S20

Part	Shelf Life	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Shelf Life Start	Adhesive	Thermal Conductivity	Thickness	Thickness	Color	Outline [x]	Outline [y]	Backing, Carrier [custom]	Backing, Carrier [custom]	Shape	Material
Bergquist GP2500S20-0.040-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	1.016 mm	0.04 in	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular
Bergquist GP2500S20-0.020-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	0.508 mm	0.02 in	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular
Bergquist GP2500S20-0.160-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	4.06 mm	0.16 "	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular
Bergquist GP2500S20-0.080-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	80 mils	0.08 in	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular
Bergquist GP2500S20-0.015-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	0.381 mm	0.015 "	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular
Bergquist GP2500S20-0.250-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	6.35 mm	0.25 in	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular	Polymer
Bergquist GP2500S20-0.100-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	2.54 mm	0.1 in	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular	Polymer
Bergquist GP2500S20-0.125-02-0816	12 Months	35 °C	95 °F	Date of Manufacture	Tacky - Both Sides	2.4 W/m-K	3.18 mm	0.125 in	Yellow	406.4 mm	203.2 mm	Fiberglass	Fiberglass	Rectangular
