EZP-Q Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

Catalog

CAP FILM 12UF 5% 330VAC RADIAL

...

Part	Lead Spacing	Lead Spacing	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	ESR (Equivalent Series Resistance)	Operating Temperature [Min]	Operating Temperature [Max]	Tolerance	Applications	Features	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Mounting Type	Voltage Rating - AC	Package / Case	Capacitance	Dielectric Material	Termination	Height - Seated (Max) [Max] [z]
Panasonic Industrial Automation Sales EZP-Q33126MTA	37.5 mm	1.476 in	1.614 "	1.181 in	30 mm	41 mm	10 mOhm	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.008 in	51 mm	Through Hole	330 V	Radial	12 µF	Metallized Polypropylene (PP)	PC Pins
Panasonic Industrial Automation Sales EZP-Q38955LTA	37.5 mm	1.476 in	1.614 "	1.181 in	30 mm	41 mm	11 mOhm	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.008 in	51 mm	Through Hole	380 V	Radial	9.5 µF	Metallized Polypropylene (PP)	PC Pins
Panasonic Industrial Automation Sales EZP-Q38156MTC	52.5 mm	2.067 in	2.264 in	1.181 in	30 mm	57.5 mm	9.3 mOhms	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.028 "		Through Hole	380 V	Radial - 4 Leads	15 µF	Metallized Polypropylene (PP)	PC Pins	51.5 mm
Panasonic Industrial Automation Sales EZP-Q33206MTB	52.5 mm	2.067 in	2.264 in	1.181 in	30 mm	57.5 mm		-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.028 "		Through Hole	330 V	Radial - 4 Leads	20 µF	Metallized Polypropylene (PP)	PC Pins	51.5 mm
Panasonic Industrial Automation Sales EZP-Q33355LTA	37.5 mm	1.476 in	1.614 "	0.669 in	17 mm	41 mm	20 mOhms	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	1.713 in		Through Hole	330 V	Radial	3.5 µF	Metallized Polypropylene (PP)	PC Pins	43.5 mm
Panasonic Industrial Automation Sales EZP-Q38855LTA	37.5 mm	1.476 in	1.614 "	1.181 in	30 mm	41 mm	11.7 mOhms	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.008 in	51 mm	Through Hole	380 V	Radial	8.5 µF	Metallized Polypropylene (PP)	PC Pins
Panasonic Industrial Automation Sales EZP-Q38905LTA	37.5 mm	1.476 in	1.614 "	1.181 in	30 mm	41 mm	11.4 mOhms	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.008 in	51 mm	Through Hole	380 V	Radial	9 µF	Metallized Polypropylene (PP)	PC Pins
Panasonic Industrial Automation Sales EZP-Q38156MTB	37.5 mm	1.476 in	1.673 in	1.496 "	38 mm	42.5 mm	7.1 mOhms	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.283 in		Through Hole	380 V	Radial	15 µF	Metallized Polypropylene (PP)	PC Pins	58 mm
Panasonic Industrial Automation Sales EZP-Q38156LTB	52.5 mm	2.067 in	2.264 in	1.181 in	30 mm	57.5 mm	9.3 mOhms	-40 °C	105 ░C	5 %	General Purpose	Long Life Low ESR	2.028 "		Through Hole	380 V	Radial	15 µF	Metallized Polypropylene (PP)	PC Pins	51.5 mm
Panasonic Industrial Automation Sales EZP-Q60225LTA	37.5 mm	1.476 in	1.634 "	1.024 "	26 mm	41.5 mm	13.3 mOhms	-40 °C	105 ░C	10 %	General Purpose	Long Life Low ESR	1.614 "		Through Hole	600 V	Radial	2.2 µF	Metallized Polypropylene (PP)	PC Pins	41 mm
