BSB01503 Series
Manufacturer: Delta Electronics
Beta
⌘K
DC FAN AXIAL SLEEVE BEARING 3V 2V TO 3.5V 0.17CFM 30DB 15 X 15 X 3.5MM
| Part | Material - Blade | Lifetime @ Temp. | Current Rating (Amps) | Voltage Range [Max] | Voltage Range [Min] | Material - Frame | Bearing Type | Fan Type | Voltage - Rated | Weight | Weight | Static Pressure | Static Pressure | Termination | Size / Dimension [x] | Size / Dimension [y] | Air Flow | Air Flow | Noise | Power (Watts) | RPM | Operating Temperature [Min] | Operating Temperature [Max] | Width [x] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | Plastic | 30000 Hrs | 50 mA | 3.5 VDC | 2 V | Plastic | Sleeve | Blower | 3 VDC | 1.36 g | 0.003 lb | 0.154 in H2O | 38.4 Pa | 3 Position Rectangular Connector | 15 mm | 15 mm | 0.005 m³/min | 0.17 CFM | 30 dB | 150 mW | 13800 RPM | -10 °C | 60 °C | 3.5 mm | Locked Rotor Protection Speed Sensor (Tach) |
