M2023TZ Series
Manufacturer: NKK Switches
Beta
⌘K
SWITCH ROCKER DPDT 6A 125V
| Part | Electrical Life | Mechanical Life | Switch Function | Mounting Type | Approval Agency | Features | Current Rating (Amps) | Voltage Rating - DC | Actuator Type | Actuator Marking | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating - AC | Termination Style | Circuit | Color - Actuator/Cap |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 25000 Steps | 50000 Cycles | On-Off-On | Through Hole | CSA UL | Epoxy Sealed Terminals | 3 A 6 A | 30 V | Actuator Arm Cap Required | Varies by Cap | 85 °C | -30 ░C | 125 V | PC Pin | DPDT | |
 NKK Switches | 25000 Steps | 50000 Cycles | On-Off-On | Through Hole | CSA UL | Epoxy Sealed Terminals | 3 A 6 A | 30 V | Concave | No Marking | 85 °C | -30 ░C | 125 V | PC Pin | DPDT | White |
 NKK Switches | 25000 Steps | 50000 Cycles | On-Off-On | Through Hole | CSA UL | Epoxy Sealed Terminals | 3 A 6 A | 30 V | Paddle | No Marking | 85 °C | -30 ░C | 125 V | PC Pin | DPDT | White |
