J01460A0 Series
Manufacturer: Telegartner Inc
Beta
⌘K
2.2-5 STRAIGHT PLUG SCREW
| Part | Body Finish | Dielectric Material | Center Contact Plating | Operating Temperature [Max] | Operating Temperature [Min] | Number of Ports | Housing Color | Contact Termination | Fastening Type | Ingress Protection | Mounting Type | Shield Termination | Connector Type | Impedance | Frequency - Max [Max] | Connector Style | Cable Group | Voltage Rating | Body Material | Center Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Telegartner Inc | White Bronze | Polytetrafluoroethylene (PTFE) | Silver | 85 °C | -40 C | 1 | Silver | Crimp Solder | Threaded | IP68 - Dust Tight Waterproof | Free Hanging (In-Line) | Clamp | Plug Male Pin | 50 Ohms | 3 GHz | 2.2/5 | ||||
Telegartner Inc | White Bronze | Polytetrafluoroethylene (PTFE) | Silver | 90 °C | -55 C | 1 | Silver | Crimp Solder | Threaded | IP67 - Dust Tight Waterproof | Free Hanging (In-Line) | Clamp | Plug Male Pin | 50 Ohms | 5 GHz | 2.2/5 | 1/4" Flex | |||
 Telegartner Inc | Silver | Polytetrafluoroethylene (PTFE) | Silver | 90 °C | -55 C | 1 | Silver | Solder | Threaded | IP68 - Dust Tight Waterproof | Free Hanging (In-Line) | Solder | Plug Male Pin | 50 Ohms | 6000 MHz | 2.2/5 | 1000 VDC | |||
 Telegartner Inc | Silver | Polytetrafluoroethylene (PTFE) | Silver | 70 °C | -30 ░C | 1 | Silver | Crimp | Threaded | IP68 - Dust Tight Waterproof | Free Hanging (In-Line) | Crimp | Plug Male Pin | 50 Ohms | 6000 MHz | 2.2/5 | LMR-240 | |||
 Telegartner Inc | Silver | Polytetrafluoroethylene (PTFE) | Silver | 90 °C | -55 C | 1 | Silver | Solder | Threaded | IP68 - Dust Tight Waterproof | Free Hanging (In-Line) Right Angle | Solder | Plug Male Pin | 50 Ohms | 6000 MHz | 2.2/5 | RG-402 | Brass | Brass | |
 Telegartner Inc | Silver | Polytetrafluoroethylene (PTFE) | Silver | 90 °C | -55 C | 1 | Silver | Solder | Threaded | IP68 - Dust Tight Waterproof | Free Hanging (In-Line) | Solder | Plug Male Pin | 50 Ohms | 6000 MHz | 2.2/5 | RG-402 | 1000 VDC | ||
 Telegartner Inc | Silver | Polytetrafluoroethylene (PTFE) | Silver | 90 °C | -55 C | 1 | Silver | Solder | Threaded | IP68 - Dust Tight Waterproof | Free Hanging (In-Line) Right Angle | Solder | Plug Male Pin | 50 Ohms | 6000 MHz | 2.2/5 | RG-401 | Brass | Brass |
