5443 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 3COND 14AWG BLACK 1000'
| Part | Voltage | Ratings | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Material | Conductor Insulation | Conductor Strand [custom] | Conductor Strand [custom] | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Features | Number of Conductors | Length | Length | Operating Temperature [Min] | Operating Temperature [Max] | Cable Type | Usage | Jacket (Insulation) Material | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ALPHA WIRE | 600 V | ISO 10993 UL Style 2501 | 1.6 mm | 0.063 in | Copper Tinned | Poly-Vinyl Chloride (PVC) | 41 | 30 AWG | Black | 10.87 mm | 0.428 in | 13.5 AWG | Biological Compatibility Rip Cord | 3 | 1000 ft | 304.8 m | -30 ░C | 105 ░C | Multi-Conductor | Communication Control | Poly-Vinyl Chloride (PVC) | ||
 ALPHA WIRE | 600 V | ISO 10993 UL Style 2501 | 1.6 mm | 0.063 in | Copper Tinned | Poly-Vinyl Chloride (PVC) | 41 | 30 AWG | Slate | 10.87 mm | 0.428 in | 13.5 AWG | Biological Compatibility Rip Cord | 3 | -30 ░C | 105 ░C | Multi-Conductor | Communication Control | Poly-Vinyl Chloride (PVC) | 30.5 m | 100 ft | ||
ALPHA WIRE | 600 V | ISO 10993 UL Style 2501 | 1.6 mm | 0.063 in | Copper Tinned | Poly-Vinyl Chloride (PVC) | 41 | 30 AWG | Slate | 10.87 mm | 0.428 in | 13.5 AWG | Biological Compatibility Rip Cord | 3 | -30 ░C | 105 ░C | Multi-Conductor | Communication Control | Poly-Vinyl Chloride (PVC) | ||||
ALPHA WIRE | 600 V | ISO 10993 UL Style 2501 | 1.6 mm | 0.063 in | Copper Tinned | Poly-Vinyl Chloride (PVC) | 41 | 30 AWG | Slate | 10.87 mm | 0.428 in | 13.5 AWG | Biological Compatibility Rip Cord | 3 | 1000 ft | 304.8 m | -30 ░C | 105 ░C | Multi-Conductor | Communication Control | Poly-Vinyl Chloride (PVC) |
