807-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 22POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Mounting Type | Flange Feature | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Finish | Card Type | Pitch | Pitch | Color | Card Thickness [Max] | Card Thickness [Min] | Termination | Features | Number of Positions | Gender | Read Out | Contact Type | Termination Rows | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 0.25 Ám | 10 Áin | 11 | Board Edge Straddle Mount | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Copper Alloy | Gold | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Extender | 22 | Female | Dual | Semi Bellows | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 11 | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Copper Alloy | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 22 | Female | Dual | Semi Bellows | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.25 Ám | 10 Áin | 22 | Through Hole | Side Mount Opening Unthreaded | 125 °C | -40 C | Copper Alloy | Gold | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | 44 | Female | Dual | Semi Bellows | 1 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | 22 | Through Hole | Side Mount Opening Unthreaded | 125 °C | -40 C | Copper Alloy | Gold | Non Specified - Single Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 22 | Female | Single | Semi Bellows | 1 | 0.128 " | 3.25 mm | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 11 | Board Edge Straddle Mount | Flush Mount Top Opening Unthreaded | 125 °C | -40 C | Copper Alloy | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Card Extender | 22 | Female | Dual | Semi Bellows | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | 22 | Through Hole | Floating Bobbin Flush Mount | 125 °C | -40 C | Copper Alloy | Gold | Non Specified - Single Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | 22 | Female | Single | Semi Bellows | 1 | 0.116 " | 2.95 mm | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 22 | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Copper Alloy | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 44 | Female | Dual | Semi Bellows | 1 | |||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 11 | Right Angle Through Hole | Flush Mount Top Opening Unthreaded | 125 °C | -40 C | Copper Alloy | Tin | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 22 | Female | Single | Semi Bellows | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.25 Ám | 10 Áin | 22 | Right Angle Through Hole | Side Mount Opening Unthreaded | 125 °C | -40 C | Copper Alloy | Gold | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 44 | Female | Dual | Semi Bellows | 1 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.25 Ám | 10 Áin | 22 | Right Angle Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Copper Alloy | Gold | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 44 | Female | Dual | Semi Bellows | 1 |
