11_PC35-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
11_PC35-50-3-4/199_UE
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Mating Cycles | Body Material | Center Contact Plating | Cable Group | Center Contact Material | Fastening Type | Shield Termination | Mounting Type | Connector Style | Frequency - Max [Max] | Number of Ports | Impedance | Contact Termination | Connector Type | Housing Color | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | -60 °C | 100 °C | Polystyrene (PS) | 500 | Stainless Steel | Gold | RG-141 | Beryllium Copper | Threaded | Solder | Free Hanging (In-Line) | 3.5mm | 26.5 GHz | 1 | 50 Ohms | Crimp | Plug Male Pin | Silver | |
 Huber+Suhner, Inc. | -60 °C | 100 °C | Polystyrene (PS) | 500 | Stainless Steel | Gold | RG-405 (.086 Semi Rigid) | Beryllium Copper | Threaded | Solder | Free Hanging (In-Line) | 3.5mm | 26.5 GHz | 1 | 50 Ohms | Crimp | Plug Male Pin | Silver | 250 V |
