GBCSHPM Series
Manufacturer: ams-OSRAM USA INC.
Beta
⌘K
LED OSLON SSL150 BLUE 470NM 3SMD
| Part | Thermal Resistance of Package | Lumens/Watt @ Current - Test | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Current - Test | Current - Max [Max] | Wavelength | Wavelength [Max] | Wavelength [Min] | Temperature - Test | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Luminous Flux @ Current/Temperature [Min] | Luminous Flux @ Current/Temperature [Max] | Viewing Angle | Mounting Type | Voltage - Forward (Vf) (Typ) | Package / Case | Package / Case | Supplier Device Package | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ams-OSRAM USA INC. | 4.6 °C/W | 76 lm/W | 3 mm | 0.118 in | 3 mm | 0.118 " | 350 mA | 1 A | 470 nm | 476 nm | 464 nm | 25 °C | 0.061 in | 1.54 mm | 39 lm | 112 lm | 150 ° | Surface Mount | 2.85 V | 3030 Metric | 1212 | 3-SMD | Blue |
