AMI-23A Series

Catalog

LINE FILTER 250VAC 4A CHASSIS

Part	Voltage - Rated AC	Frequency - Operating	Applications	Filter Type	Approval Agency	Termination Style	Configuration	Inductance	Operating Temperature [Max]	Operating Temperature [Min]	Current	Mounting Type
Altran Magnetics, LLC AMI-23A-4-3	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect	Single Stage	14 mH	100 °C	-25 °C	4 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-6-1	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect	Single Stage	8 mH	100 °C	-25 °C	6 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-20-3	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect Threaded Post (M4)	Single Stage	4 mH	100 °C	-25 °C	20 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-20-1	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus		Single Stage	4 mH	100 °C	-25 °C	20 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-16-1	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus		Single Stage	4 mH	100 °C	-25 °C	16 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-12-1	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect	Single Stage	4 mH	100 °C	-25 °C	12 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-1-3	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect	Single Stage	20 mH	100 °C	-25 °C	1 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-16-3	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect Wire Leads	Single Stage	4 mH	100 °C	-25 °C	16 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-10-3	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect	Single Stage	8 mH	100 °C	-25 °C	10 A	Chassis Mount
Altran Magnetics, LLC AMI-23A-20-6	250 V	DC ~ 400Hz	Safety	Single Phase	CE cURus	Quick Connect Threaded Post (M4)	Single Stage	4 mH	100 °C	-25 °C	20 A	Chassis Mount
