F221B3/8 Series

Catalog

HEATSHRINK 3/8 IN X 4FT BLACK

Part	Shelf Life Start	Type	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Recovered Wall Thickness	Recovered Wall Thickness	Material	Shrink Temperature	Features	Color	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Shelf Life	Length [x]	Length [x]	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Length	Length	Length	Length [x]
ALPHA WIRE F221B3/8 BK100	Date of Manufacture	Tubing Flexible	0.187 in	4.75 mm	0.025 in	0.64 mm	Polyolefin (PO) Irradiated	90 °C	Flame Resistant Fluid Resistant UV Resistant	Black	0.375 in	9.53 mm	144 Months	4 ft	1.22 m	1	2	-55 C	135 °C
ALPHA WIRE F221B3/8 BK202	Date of Manufacture	Tubing Flexible	0.187 in	4.75 mm	0.025 in	0.64 mm	Polyolefin (PO) Irradiated	90 °C	Flame Resistant Fluid Resistant UV Resistant	Black	0.375 in	9.53 mm	144 Months	0.25 ft 0.333 ft	76.2 mm	1	2	-55 C	135 °C	19.05 mm 25.4 mm 38.1 mm 50.8 mm 61 m 101.6 mm 152.4 mm	0.062 ft 0.083 ft 0.125 ft 0.167 ft 0.5 ' 200 ft	0.75 " 1 " 1.5 in 2 in 4 in 6 "	3 in
ALPHA WIRE F221B3/8 CL202	Date of Manufacture	Tubing Flexible	0.187 in	4.75 mm	0.025 in	0.64 mm	Polyolefin (PO) Irradiated	90 °C	Fluid Resistant	Clear	0.375 in	9.53 mm	144 Months	0.25 ft 0.333 ft	76.2 mm	1	2	-55 C	135 °C	19.05 mm 25.4 mm 38.1 mm 50.8 mm 61 m 101.6 mm 152.4 mm	0.062 ft 0.083 ft 0.125 ft 0.167 ft 0.5 ' 200 ft	0.75 " 1 " 1.5 in 2 in 4 in 6 "	3 in
