AML23 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH TOGGLE SPDT 3A 125V
| Part | Illumination | Voltage Rating - DC | Circuit | Electrical Life | Termination Style | Switch Function | Illumination Type, Color | Mounting Type | Actuator Type | Current Rating (Amps) | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Voltage Rating - AC | Illumination Voltage (Nominal) | Termination Style | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Honeywell Sensing and Productivity Solutions | Illuminated | 24 V | SPDT | 25000 Steps | PC Pin | On-Off-On | Incandescent | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | |||
Honeywell Sensing and Productivity Solutions | Illuminated | 24 V | SPDT | 25000 Steps | Quick Connect Solder | On-Off-Mom | Incandescent | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | 24 VAC/DC | 0.11 in | 2.8 mm |
Honeywell Sensing and Productivity Solutions | Non-Illuminated | 24 V | DPDT | 25000 Steps | Quick Connect Solder | Mom-On-Mom | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | 0.11 in | 2.8 mm | ||
Honeywell Sensing and Productivity Solutions | Illuminated | 24 V | DPDT | 25000 Steps | Quick Connect Solder | On-On-Mom | Incandescent | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | 0.11 in | 2.8 mm | |
Honeywell Sensing and Productivity Solutions | Non-Illuminated | 24 V | DPDT | 25000 Steps | Quick Connect Solder | On-Off-On | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | 0.11 in | 2.8 mm | ||
 Honeywell Sensing and Productivity Solutions | Non-Illuminated | 24 V | DPDT | 25000 Steps | Quick Connect Solder | On-On | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | 0.11 in | 2.8 mm | ||
 Honeywell Sensing and Productivity Solutions | Non-Illuminated | 125 VDC | DPDT | 25000 Steps | Quick Connect Solder | On-Off-Mom | Panel Mount Snap-In | Paddle | 100 mA | 19.05 mm | 28.98 mm | 125 V | 0.11 in | 2.8 mm | ||
Honeywell Sensing and Productivity Solutions | Non-Illuminated | 24 V | 4PDT | 25000 Steps | PC Pin | On-On-On | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | ||||
 Honeywell Sensing and Productivity Solutions | Non-Illuminated | 24 V | SPDT | 25000 Steps | Quick Connect Solder | Mom-Off-Mom | Panel Mount Snap-In | Paddle | 2 A 3 A | 19.05 mm | 28.98 mm | 125 V | 0.11 in | 2.8 mm | ||
 Honeywell Sensing and Productivity Solutions | Non-Illuminated | 125 VDC | DPDT | 25000 Steps | Quick Connect Solder | On-Off-On | Panel Mount Snap-In | Paddle | 100 mA | 19.05 mm | 28.98 mm | 125 V | 0.11 in | 2.8 mm |
