621-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
STANDARD D-SUN CONNECTOR ROHS COMPLIANT: YES
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Connector Style | Termination | Flange Feature | Features | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Material, Finish | Contact Type | Mounting Type | Current Rating (Amps) | Connector Type | Backset Spacing | Backset Spacing | Number of Positions | Material Flammability Rating | Number of Rows [custom] | Contact Finish | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | D-Sub | Solder | 4-40 Mating Side Female Screwlock | Filter Grounding Indents Mounting Brackets Shielded | 30 Áin | 0.76 Ám | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | D-Sub | Solder | 4-40 | Grounding Indents Mounting Brackets Shielded | 15 µin | 0.38 µm | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | D-Sub | Solder | Housing/Shell (Unthreaded) | Filter Grounding Indents Mounting Brackets Shielded | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | D-Sub | Solder | Mating Side Female Screwlock (M3) | Grounding Indents Mounting Brackets Shielded | 15 µin | 0.38 µm | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | D-Sub | Solder | Mating Side Female Screwlock (M3) | Filter Grounding Indents Mounting Brackets Shielded | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | D-Sub | Solder | Mating Side Female Screwlock (M3) | Filter Grounding Indents Mounting Brackets Shielded | 15 µin | 0.38 µm | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | D-Sub | Solder | Housing/Shell (M3) | Filter Grounding Indents Mounting Brackets Shielded | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | D-Sub | Solder | Housing/Shell (Unthreaded) | Board Lock Filter Grounding Indents Mounting Brackets Shielded | 30 Áin | 0.76 Ám | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | D-Sub | Solder | Housing/Shell (M3) | Board Lock Grounding Indents Mounting Brackets Shielded | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | D-Sub | Solder | Housing/Shell | Board Lock Filter Grounding Indents Mounting Brackets Shielded | 30 Áin | 0.76 Ám | 1 | DE E | Nickel Plated Steel | Signal | Board Edge Right Angle Through Hole | 3 A | Plug Male Pins | 8.08 mm | 0.318 " | 9 | UL94 V-0 | 2 | Gold | 4-40 |
