MCX7 Series
RF Connectors / Coaxial Connectors 75 Ohm MCX Plug, Cable Termination
Manufacturer: Samtec Inc.
Catalog
RF Connectors / Coaxial Connectors 75 Ohm MCX Plug, Cable Termination
Beta
⌘K
RF Connectors / Coaxial Connectors 75 Ohm MCX Plug, Cable Termination
RF Connectors / Coaxial Connectors 75 Ohm MCX Plug, Cable Termination
RF Connectors / Coaxial Connectors 75 Ohm MCX Plug, Cable Termination
| Part | Voltage Rating | Body Material | Dielectric Material | Impedance | Connector Style | Number of Ports | Center Contact Material | Cable Group | Housing Color | Center Contact Plating | Contact Termination | Mounting Type | Connector Type | Shield Termination | Body Finish | Frequency - Max [Max] | Fastening Type | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Samtec Inc. | 170 V | Brass | Polytetrafluoroethylene (PTFE) | 75 Ohms | MCX | 1 | Beryllium Copper | RG-179 | Gold | Gold | Solder | Free Hanging (In-Line) Right Angle | Male Pin Plug | Crimp | Gold | 6000 MHz | Snap-On | 125 °C | -65 ░C |
