887-028 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 28POS 0.156
...
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Number of Positions/Bay/Row | Read Out | Gender | Color | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Card Type | Contact Type | Termination | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Flange Feature | Pitch | Pitch | Contact Finish | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 2 | 14 | Dual | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Cantilever | Solder Eyelet(s) | Copper Alloy | 125 °C | -40 C | Through Hole | M3 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | Gold | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 28 | Single | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Cantilever | Solder | Copper Alloy | 125 °C | -40 C | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Gold | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 28 | Single | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Cantilever | Solder | Copper Alloy | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Gold | 1 | 1 | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 2 | 14 | Dual | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Cantilever | Solder | Copper Alloy | 125 °C | -40 C | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Gold | 0.156 " | 3.96 mm | Card Extender | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 28 | Single | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Cantilever | Solder | Copper Alloy | 125 °C | -40 C | Right Angle Through Hole | Flush Mount Side Opening Unthreaded | 3.96 mm | 0.156 in | Gold | 1 | 1 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 28 | Single | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Cantilever | Solder Eyelet(s) | Copper Alloy | 125 °C | -40 C | Through Hole | M3 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | Gold | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 2 | 14 | Dual | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Cantilever | Solder Eyelet(s) | Copper Alloy | 125 °C | -40 C | Through Hole | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Gold | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 28 | Single | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Cantilever | Wire Wrap | Copper Alloy | 125 °C | -40 C | Through Hole | 4-40 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | Gold | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 2 | 14 | Dual | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Cantilever | Solder | Copper Alloy | 125 °C | -40 C | Through Hole | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Gold | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 28 | Single | Female | Black | 0.25 Ám | 10 Áin | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Cantilever | Solder | Copper Alloy | 125 °C | -40 C | Through Hole | Flush Mount Side Opening Unthreaded | 3.96 mm | 0.156 in | Gold | 1 | 1 | 0.128 " | 3.25 mm |
