MX7537 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC DAC 12BIT A-OUT 24SOIC

Part	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Settling Time	Voltage - Supply, Analog [Min]	Voltage - Supply, Analog [Max]	Number of Bits	Package / Case	Package / Case [custom]	Package / Case [custom]	Architecture	Supplier Device Package	Voltage - Supply, Digital [Min]	Voltage - Supply, Digital [Max]	INL/DNL (LSB)	Reference Type	Data Interface	Output Type	INL/DNL (LSB)	Supplier Device Package [y]	Supplier Device Package [x]	Package / Case
Analog Devices Inc./Maxim Integrated MX7537LCWG+	Surface Mount	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	24-SOIC	7.5 mm	0.295 in	R-2R	24-SOIC	10.8 V	16.5 V	0.5 LSB 1 LSB	External	Parallel	Current - Unbuffered
Analog Devices Inc./Maxim Integrated MX7537JEWG+T	Surface Mount	85 °C	-40 C	1.5 µs	10.8 V	16.5 V	12	24-SOIC	7.5 mm	0.295 in	R-2R	24-SOIC	10.8 V	16.5 V		External	Parallel	Current - Unbuffered	±1 (Max)
Analog Devices Inc./Maxim Integrated MX7537JCWG+	Surface Mount	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	24-SOIC	7.5 mm	0.295 in	R-2R	24-SOIC	10.8 V	16.5 V		External	Parallel	Current - Unbuffered	±1 (Max)
Analog Devices Inc./Maxim Integrated MX7537LP+T	Surface Mount	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	28-LCC (J-Lead)			R-2R	28-PLCC	10.8 V	16.5 V	0.5 LSB 1 LSB	External	Parallel	Current - Unbuffered		11.51	11.51
Analog Devices Inc./Maxim Integrated MX7537JEWG+	Surface Mount	85 °C	-40 C	1.5 µs	10.8 V	16.5 V	12	24-SOIC	7.5 mm	0.295 in	R-2R	24-SOIC	10.8 V	16.5 V		External	Parallel	Current - Unbuffered	±1 (Max)
Analog Devices Inc./Maxim Integrated MX7537JCWG+T	Surface Mount	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	24-SOIC	7.5 mm	0.295 in	R-2R	24-SOIC	10.8 V	16.5 V		External	Parallel	Current - Unbuffered	±1 (Max)
Analog Devices Inc./Maxim Integrated MX7537KN+	Through Hole	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	24-DIP			R-2R	24-PDIP	10.8 V	16.5 V	0.5 LSB 1 LSB	External	Parallel	Current - Unbuffered				0.3 in 7.62 mm
Analog Devices Inc./Maxim Integrated MX7537LP+	Surface Mount	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	28-LCC (J-Lead)			R-2R	28-PLCC	10.8 V	16.5 V	0.5 LSB 1 LSB	External	Parallel	Current - Unbuffered		11.51	11.51
Analog Devices Inc./Maxim Integrated MX7537JP+T	Surface Mount	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	28-LCC (J-Lead)			R-2R	28-PLCC	10.8 V	16.5 V		External	Parallel	Current - Unbuffered	±1 (Max)	11.51	11.51
Analog Devices Inc./Maxim Integrated MX7537JP+	Surface Mount	70 °C	0 °C	1.5 µs	10.8 V	16.5 V	12	28-LCC (J-Lead)			R-2R	28-PLCC	10.8 V	16.5 V		External	Parallel	Current - Unbuffered	±1 (Max)	11.51	11.51
