M83513/22 Series
Manufacturer: Cinch Connectivity Solutions
Beta
⌘K
CONN MICRO-D PLUG 9POS VERT SLDR
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Connector Type | Material Flammability Rating | Contact Type | Shell Material, Finish | Connector Style | Mounting Type | Contact Finish | Number of Rows [custom] | Termination | Flange Feature | Number of Positions | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | 50 µin | 1.27 µm | 3 A | 0.05 | 0.05 | Plug Male Pins | UL94 V-0 | Signal | Aluminum Alloy Electroless Nickel Plated | D-Type Micro-D | Through Hole | Gold | 2 | Solder | Mating Side Female Screwlock (2-56) | 9 | |
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | 50 µin | 1.27 µm | 3 A | 0.05 | 0.05 | Plug Male Pins | UL94 V-0 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | D-Type Micro-D | Through Hole | Gold | 2 | Solder | Mating Side Female Screwlock (2-56) | 21 | |
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | 50 µin | 1.27 µm | 3 A | 0.05 | 0.05 | Plug Male Pins | UL94 V-0 | Signal | Aluminum Alloy Electroless Nickel Plated | D-Type Micro-D | Through Hole | Gold | 2 | Solder | Mating Side Female Screwlock (2-56) | 37 | |
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | 50 µin | 1.27 µm | 3 A | 0.05 | 0.05 | Plug Male Pins | UL94 V-0 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | D-Type Micro-D | Through Hole | Gold | 2 | Solder | Mating Side Female Screwlock (2-56) | 15 | |
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | 50 µin | 1.27 µm | 3 A | 0.05 | 0.05 | Plug Male Pins | UL94 V-0 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | D-Type Micro-D | Through Hole | Gold | 2 | Solder | Mating Side Female Screwlock (2-56) | 25 | |
Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | 50 µin | 1.27 µm | 3 A | 0.05 | 0.05 | Plug Male Pins | UL94 V-0 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | D-Type Micro-D | Through Hole | Gold | 2 | Solder | Mating Side Female Screwlock (2-56) | 31 |
