837-026 Series
Manufacturer: EDAC Inc.
Beta
⌘K
837 HIGH TEMP' SERIES (.156" (3.
| Part | Material - Insulation | Termination Rows [custom] | Termination | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Color | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Mounting Type | Pitch | Pitch | Read Out | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Gender | Number of Positions | Termination Rows | Flange Feature | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Dual | Cantilever | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 13 | 0.25 Ám | 10 Áin | Female | 26 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Single | Cantilever | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | Female | 26 | 1 | M3 Threaded Insert Top Mount Opening | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | 125 °C | -40 C | Gold | Right Angle Through Hole | 3.96 mm | 0.156 in | Single | Cantilever | 0.116 " | 2.95 mm | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | Female | 26 | 1 | Floating Bobbin Top Mount Opening | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Dual | Cantilever | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 13 | 0.25 Ám | 10 Áin | Female | 26 | Flush Mount Top Opening Unthreaded | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Dual | Cantilever | Non Specified - Dual Edge | 13 | 0.25 Ám | 10 Áin | Female | 26 | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Single | Cantilever | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | Female | 26 | 1 | Flush Mount M3 Threaded Insert Top Opening | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Single | Cantilever | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | Female | 26 | 1 | 1 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Dual | Cantilever | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 13 | 0.25 Ám | 10 Áin | Female | 26 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | 125 °C | -40 C | Gold | Through Hole | 3.96 mm | 0.156 in | Single | Cantilever | 0.116 " | 2.95 mm | Non Specified - Single Edge | 26 | 0.25 Ám | 10 Áin | Female | 26 | 1 | Floating Bobbin Flush Mount | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Green | Copper Alloy | 125 °C | -40 C | Gold | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Dual | Cantilever | Non Specified - Dual Edge | 13 | 0.25 Ám | 10 Áin | Female | 26 | 4-40 Flush Mount Threaded Insert Top Opening | Card Extender |
