PNG-3 Series

Catalog

CABLE GLAND 13-18.01MM 3/4" NPT

Part	Panel Hole Size	Panel Hole Size	Thread Size	Thread Length	Thread Length	Outside Cable Diameter (Max) [Max] [diameter]	Outside Cable Diameter (Max) [Max] [diameter]	Outside Cable Diameter (Min) [Min]	Outside Cable Diameter (Min) [Min]	Color	Type	Ingress Protection	Operating Temperature [Min]	Operating Temperature [Max]	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Max) [Max]	Outside Cable Diameter (Max)
SAB North America PNG-3/4	1.05 in	26.7 mm	0.75 "	0.591 in	15 mm	18.01 mm	0.709 in	13 mm	0.512 in	Black	Cable Gland	IP68 - Dust Tight Waterproof	-20 ░C	100 °C
SAB North America PNG-3/8	0.675 in	17.2 mm	0.375 in NPT	0.591 in	15 mm	10 mm	0.394 in			Gray	Cable Gland	IP68 - Dust Tight Waterproof	-20 ░C	100 °C	0.197 in	5 mm
SAB North America PNG-3/4R	1.05 in	26.7 mm	0.75 "	0.591 in	15 mm					Gray	Cable Gland	IP68 - Dust Tight Waterproof	-20 ░C	100 °C	0.354 in	9 mm	0.63 in	16 mm
