622-M25 Series
Manufacturer: EDAC Inc.
Beta
⌘K
622M SERIES RIGHT ANGLE D-SUB PL
| Part | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Connector Type | Contact Type | Contact Finish | Mounting Type | Material Flammability Rating | Backset Spacing | Backset Spacing | Termination | Number of Rows [custom] | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Connector Style | Current Rating (Amps) | Features | Flange Feature | Flange Feature | Shell Material, Finish | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | 0.38 µm | 15 µin | D-Sub | 5 A | Board Lock Mounting Brackets Shielded | Housing/Shell | 4-40 | Nickel Plated Steel | |
 EDAC Inc. | Copper Alloy | Blue | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | 0.38 µm | 15 µin | D-Sub | 5 A | Shielded | Housing/Shell | 4-40 | ||
 EDAC Inc. | Copper Alloy | Blue | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | D-Sub | 5 A | Board Lock Mounting Brackets Shielded | Housing/Shell | 4-40 | Nickel Plated Steel | Flash | ||
 EDAC Inc. | Copper Alloy | Green | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | 0.38 µm | 15 µin | D-Sub | 5 A | Shielded | Housing/Shell | 4-40 | ||
 EDAC Inc. | Copper Alloy | Green | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | 0.76 Ám | 30 Áin | D-Sub | 5 A | Shielded | Housing/Shell (Unthreaded) | |||
 EDAC Inc. | Copper Alloy | White | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | D-Sub | 5 A | Mounting Brackets Shielded | 4-40 | Flash | ||||
 EDAC Inc. | Copper Alloy | Blue | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | 0.38 µm | 15 µin | D-Sub | 5 A | Mounting Brackets Shielded | 4-40 | |||
 EDAC Inc. | Copper Alloy | Green | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | D-Sub | 5 A | Shielded | Housing/Shell | 4-40 | Flash | |||
 EDAC Inc. | Copper Alloy | White | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | D-Sub | 5 A | Shielded | Housing/Shell | 4-40 | Flash | |||
 EDAC Inc. | Copper Alloy | Blue | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Receptacle Female Sockets | Signal | Gold | Board Edge Right Angle Through Hole | UL94 V-0 | 7.2 mm | 0.283 in | Solder | 2 | B DB | 3 | 25 | 0.76 Ám | 30 Áin | D-Sub | 5 A | Board Lock Mounting Brackets Shielded | 4-40 |
