395-106 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Material - Insulation | Termination Rows [custom] | Gender | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Number of Positions | Card Type | Pitch | Pitch | Color | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Number of Rows [custom] | Contact Material | Contact Finish | Flange Feature | Termination | Features | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Card Guides | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | Card Guides | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | M3 Threaded Insert Top Mount Opening | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Right Angle Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | Floating Bobbin Flush Mount | Solder | Card Extender | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Right Angle Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Card Guides | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Right Angle Through Hole | 0.25 Ám | 10 Áin | Cantilever | 106 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Black | -40 C | 105 ░C | Dual | 2 | Copper Alloy | Gold | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.156 " | 3.96 mm |
