000209 Series
Manufacturer: Molex
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
CONN SOCKET 14-18AWG CRIMP TIN
| Part | Contact Finish | Wire Gauge (AWG) (Max) | Wire Gauge (AWG) (Min) | Pin or Socket | Contact Termination | Contact Finish Thickness | Type | Contact Material |
|---|---|---|---|---|---|---|---|---|
 Molex | Tin | 18 AWG | 14 AWG | Socket | Crimp | 20 µin | Power | |
 Molex | Tin | 24 AWG | 22 AWG | Socket | Crimp | 20 µin | Power | |
Molex | Gold | 22 AWG | 18 AWG | Socket | Crimp | 50 µin | ||
Molex | ||||||||
 Molex | Gold | 30 AWG | 24 AWG | Socket | Crimp | 15 µin | Power | |
 Molex | Tin | 22 AWG | 18 AWG | Pin | Crimp | 20 µin | Power | |
 Molex | Gold | 20.5 AWG | 14 AWG | Pin | Crimp | 15 µin | Power Stamped | Brass |
 Molex | Tin | 20.5 AWG | 14 AWG | Socket | Crimp | 20 µin | Power | |
Molex | ||||||||
 Molex | Tin | 20.5 AWG | 14 AWG | Socket | Crimp | 20 µin | Power |
