UF200 Series

Catalog

FAN AXIAL 200X71MM 115VAC TACH

Part	Current Rating (Amps)	Material - Blade	Material - Frame	Noise	Size / Dimension [x]	Size / Dimension [z]	Width [y]	RPM	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Voltage - Rated	Air Flow	Air Flow	Fan Type	Bearing Type	Termination	Weight	Weight	Static Pressure	Static Pressure	Approval Agency	Features
Mechatronics Fan Group UF200BMB12-H2C2A-B1	880 mA	Metal	Metal	61 dB(A)	225 mm	225 mm	80 mm	3000 RPM	-20 ░C	70 °C	100 W	115 VAC	625 CFM	17.5 m³/min	Tubeaxial	Ball	4	1.4 kg	3 lb	201.8 Pa	0.81 in H2O	CE cUL TUV UL	Permanent Split Capacitor Motor Speed Sensor (Tach) Thermal Overload Protector (TOP)
Mechatronics Fan Group UF200BMB12-H2C2B	880 mA	Metal	Metal	61 dB(A)	225 mm	225 mm	80 mm	3000 RPM	-20 ░C	70 °C	100 W	115 VAC	625 CFM	17.5 m³/min	Frameless Tubeaxial	Ball	4	1.4 kg	3 lb	201.8 Pa	0.81 in H2O	CE cUL TUV UL	Permanent Split Capacitor Motor Thermal Overload Protector (TOP)
Mechatronics Fan Group UF200BMB23-H2C2A	0.37 A	Metal	Metal	61 dB(A)	225 mm	225 mm	80 mm	3000 RPM	-20 ░C	70 °C	80 W	230 VAC	625 CFM	17.5 m³/min	Tubeaxial	Ball	4	1.4 kg	3 lb	201.8 Pa	0.81 in H2O	CE cUL TUV UL	Permanent Split Capacitor Motor Thermal Overload Protector (TOP)
Mechatronics Fan Group UF200BMB23-H2C2A-B1	0.37 A	Metal	Metal	61 dB(A)	225 mm	225 mm	80 mm	3000 RPM	-20 ░C	70 °C	80 W	230 VAC	625 CFM	17.5 m³/min	Tubeaxial	Ball	4	1.4 kg	3 lb	201.8 Pa	0.81 in H2O	CE cUL TUV UL	Permanent Split Capacitor Motor Speed Sensor (Tach) Thermal Overload Protector (TOP)
Mechatronics Fan Group UF200BMB12-H2C2A	880 mA	Metal	Metal	61 dB(A)	225 mm	225 mm	80 mm	3000 RPM	-20 ░C	70 °C	100 W	115 VAC	625 CFM	17.5 m³/min	Tubeaxial	Ball	4	1.4 kg	3 lb	201.8 Pa	0.81 in H2O	CE cUL TUV UL	Permanent Split Capacitor Motor Thermal Overload Protector (TOP)
