846-005 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 5POS 0.125
| Part | Material - Insulation | Termination Rows | Contact Type | Gender | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Finish | Termination | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Mounting Type | Number of Positions/Bay/Row | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Read Out |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Solder | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Wire Wrap | Green | 0.156 " | 3.96 mm | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Solder | Green | M3 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Solder | Green | 0.128 " | 3.25 mm | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Solder Eyelet(s) | Green | 0.128 " | 3.25 mm | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Wire Wrap | Green | M3 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Wire Wrap | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Solder | Green | M3 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Solder | Green | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Female | 1 | 0.25 Ám | 10 Áin | 5 | Gold | Solder | Green | Flush Mount M3 Threaded Insert Top Opening | 3.18 mm | 0.125 in | Right Angle Through Hole | 5 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Single |
