837-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 36POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Rows | Contact Type | Card Type | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Color | Pitch | Pitch | Contact Material | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Read Out | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Gender | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Cantilever | Non Specified - Single Edge | 36 | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Single | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | Female | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Cantilever | Non Specified - Single Edge | 36 | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Solder | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Female | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Cantilever | Non Specified - Single Edge | 36 | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Wire Wrap | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | Female | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Cantilever | Non Specified - Single Edge | 36 | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Solder Eyelet(s) | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Female | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | Non Specified - Dual Edge | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Dual | Solder | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Female | 2 | 2 | 18 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Cantilever | Non Specified - Single Edge | 36 | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Wire Wrap | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Female | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | Non Specified - Dual Edge | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Dual | Wire Wrap | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Female | 2 | 2 | 18 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | Non Specified - Dual Edge | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Dual | Solder | 0.25 Ám | 10 Áin | Female | 2 | 2 | 18 | Card Extender | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | Non Specified - Dual Edge | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Dual | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Female | 2 | 2 | 18 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 1 | Cantilever | Non Specified - Single Edge | 36 | 125 °C | -40 C | 36 | Green | 3.96 mm | 0.156 in | Copper Alloy | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Wire Wrap | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Female |
