ERJ-S02 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

SMD CHIP RESISTOR, 2 KOHM, ± 0.5%, 100 MW, 0402 [1005 METRIC], THICK FILM, SULFUR RESISTANT

...

Part	Number of Terminations	Features	Composition	Resistance	Power (Watts)	Power (Watts)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Temperature Coefficient	Ratings	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Supplier Device Package	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Tolerance
Panasonic Industrial Automation Sales ERJ-S02D2001X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	2 kOhms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C
Panasonic Industrial Automation Sales ERJ-S02F2322X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	23.2 kOhms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C	1 %
Panasonic Industrial Automation Sales ERJ-S02D2151X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	2.15 kOhms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C
Panasonic Industrial Automation Sales ERJ-S02D4303X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	430 kOhms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C
Panasonic Industrial Automation Sales ERJ-S02D8871X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	8.87 kOhms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C
Panasonic Industrial Automation Sales ERJ-S02J201X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	200 Ohms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C	5 %
Panasonic Industrial Automation Sales ERJ-S02D82R0X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	82 Ohms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C
Panasonic Industrial Automation Sales ERJ-S02D12R4X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	12.4 Ohms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C
Panasonic Industrial Automation Sales ERJ-S02F2940X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	294 Ohms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C	1 %
Panasonic Industrial Automation Sales ERJ-S02F7153X	2	Anti-Sulfur Automotive AEC-Q200	Thick Film	715 kOhms	0.1 W	0.1 W	0.016 in	0.4 mm	200 ppm/°C	AEC-Q200	1 mm	0.02 in	0.5 mm	0.039 in	0402	0402 (1005 Metric)	155 °C	-55 °C	1 %
